Month: January 2022

What It’s Like to Be an Entry-Level Aviation Engineer

As a new aviation engineer, I experience a good mix of both office and fieldwork. The beauty of the job is being heavily involved in the design process of a project and then seeing the project develop in real life.

I have the opportunity to travel to new places and go sightseeing. In the past six months, I visited 22 airports across New England. Out of all the states in New England, I’d say Massachusetts had the best airports to work on. I got the chance to work at Provincetown Municipal Airport at the tip of Cape Cod and Martha’s Vineyard Airport. Working at the Nantucket Memorial Airport, I was able to see the beach from the runway.

“I got a chance to work at the Provincetown Municipal Airport.”

Massachusetts’s airports varied a lot in size. Some airports were located in residential areas and only took light aircraft, whereas others were located in business districts and took commercial airlines. On these airports, I conducted PCI inspections alongside another engineer. We looked for pavement distresses such as fatigue cracking, weathering, and rutting on the runways, taxiways, and aprons. With this information, we developed a pavement maintenance plan to determine which pavement sections were a priority in fixing. Among the 22 airports, one of them was a joint civil-military airport. Westfield-Barnes Regional Airport, also known as Barnes Air National Guard Base, had F-15 aircrafts while I was there. Being so close to the runway, it was a very cool sight to see the F-15s taking off and landing.

As for entering the field during a pandemic, there was nothing different from pre-pandemic times other than wearing a mask. Each state varied with its regulations and protocols, but the mask mandate was common for all states.

My work experience across the New England airports has made me grow a lot as an engineer. I have dealt with various projects ranging from fence relocation projects to runway extension projects. It was a plus to work near tourist destinations such as the mountains in Maine or the beaches on Cape Cod.

Employee Spotlight: Robby Moon

Employee Spotlight featured image of Robby Moon, Airport Engineer, and his brother

Robby Moon – Airport Engineer & Great Brother

1. What drew you to Hoyle Tanner?

My former supervisor had worked in aviation and hearing about what he did, drew me into the aviation field. One of my peers had recommended Hoyle Tanner because they had an aviation group.

2. What’s something invaluable you’ve learned here? (Please elaborate your answer)

I’ve learned a lot about engineering, so I can’t choose just one thing. But, for the lunch hour, I’ve learned that at the Gyro Spot on Elm Street, ordering the chicken burrito with sauce on the side because sauce in the burrito makes the tortilla soggy.

3. What’s your favorite time of year to work at Hoyle Tanner & why?

Summer is my favorite time of the year to work at Hoyle Tanner because that is when projects are under construction. I travel a lot and get to see a lot of really cool places during the construction season.

4. What’s the coolest thing you are working on, and why?

The coolest thing I am working on is finding the required soil filter area for Pittsfield Municipal Airport in Maine. Dealing with soil filters and drainage is something new for me.

5. What’s the best thing that’s happened to you so far this week?

I went to Disney World and met my brother and his family!

6. How many different states have you lived in?

Three states: New York, Maine and New Hampshire

7. If you could only eat one meal for the rest of your life what would it be?

The spicy chicken sandwich from Chick-fil-A

8. What kind of pet do you have and how did you choose to name it?

I currently do not have any pets, but I used to have a dog named Wolfie. I named him Wolfie because he looked like a wolf.

9. What is a fun or interesting fact about your hometown?

The Treaty of Portsmouth that ended the Russo-Japanese War of 1904-1905 was signed in Portsmouth, New Hampshire.

10. What are three things still left on your bucket list?

  1. See the Eiffel Tower
  2. Go to a Brad Paisley concert
  3. Own a house

11. Name three items you’d take with you to a desert island

  1. Fishing pole
  2. Lighter
  3. Knife

12. What characteristic do you admire most in others?

Integrity

13. How old is the oldest item in your closet?

My dad’s AC/DC vinyl records that are about 35-years-old.

14. Words to live by? Favorite quote? Why?

“You miss 100% of the shots you don’t take.” – Wayne Gretzky. I find this quote inspiring because it shows that you can’t succeed unless you try.

15. What did you want to be when you were growing up?

I wanted to be a NBA player.

16. If you were to skydive from an airplane what would you think about on the way down?

I would probably be in too much shock to have any thoughts.

Can We Predict Black Ice – Factors to Prepare Winter Roadway Treatments

Snow covered road

Winter is officially here, which means icy temperatures, snow days and longer nights. This time of year we all pay a little closer attention to the weather and in particular, how it could potentially affect driving conditions. The idea that pavement temperature directly corresponds to air temperature is a common misconception and is in fact only one of several factors that needs to be taken into consideration. Air and pavement temperatures can differ by several degrees. The difference is critical in predicting and preparing for black ice, which poses a serious threat to all motorists each year because of the difficulty it takes to identify.

Forecasting pavement temperatures and conditions is difficult but not impossible. When predicting conditions, four major factors are considered: air, sun, moisture, and the amount of heat beneath the pavement.

Air:

According to the Law of Thermodynamics, every object is in a constant state of temperature change. If you place a cold object in a warm room, the temperature of that object will steadily increase; if you place a warm object in a cold room, the temperature of the object will decrease. If you hold the temperature of the room constant, the object will adjust accordingly until it reaches room temperature. Roadways are no exception to this rule. However, the balance of heat is a gradual process and the speed by which it occurs is heavily dependent on several factors, such as surface area, density and material. For example, in the event of a temperature drop, a bridge (which is exposed to the air on all four sides and made of metal and concrete) will cool faster than the street, with only one surface area exposed to the air.

Below the Pavement:

It’s easy to forget what isn’t out there in the open for us to see. Half of the pavement surface area is affected by the ground beneath it, so subsurface temperatures play an equally important role when considering pavement temperature.

In the fall, the pavement is usually warmer than the air because the subsurface temperatures are still cooling down from the summer months.

In the spring the air is warmer than the pavement because a lot of the ground is still thawing from months of below freezing temperatures.

During a snowstorm the air is below freezing; snow may accumulate but if the ground underneath is warmer than the outside air, the snow will melt.

In addition, rain falling on pavement atop freezing subsurface temperatures may be enough to freeze over the roads.

While this general information is good to know as a guideline, accurate subsurface temperatures can only be measured with a Road Weather Information System (RWIS) installed by the department of transportation. Therefore, it is best to be cautious on the roads when seasons are changing, especially if you’re in a new area.

Sun:

Even in the winter, the sun still has a huge influence on pavement temperatures. It is so powerful, in fact, that a cloudy day can cause a decrease in the pavement temperature by 10 degrees. Despite cold and miserable weather conditions the pavement is constantly being affected by solar radiation. When dealing with the effects of radiation, a meteorologist considers elevation as an additional factor. Higher elevation means closer proximity to the sun and increased exposure to radiation.

Moisture:

Rain, snow and water vapor are the three forms of moisture in the atmosphere. Just like cooler temperatures, rain and snow typically cool down the surface of the pavement. The harder the rain or snow falls the faster the pavement will cool down.

Out of the three forms, water vapor is the most difficult form of moisture in the atmosphere to measure, because you cannot visibly see it. The most commonly accepted form of measuring water vapor in the air is dew point; the temperature below which water condensation occurs. The greater the difference between dew point and the air temperature, the drier the air. We know from the water cycle that once rain falls, it will evaporate back into the air. Evaporation requires heat to occur and there is heat in the pavement. Therefore, the drier the air, the faster evaporation will occur and in conclusion the faster the pavement will cool.

Finally, it is important to understand how air temperature and moisture come together in the formation of black ice. A dangerous misconception is that it needs to be snowing or raining for black ice to occur. Black ice usually occurs when the dew point and air temperatures converge. At this point, the air can no longer hold the moisture, so it condenses onto the pavement. Black ice can also occur when the air temperature is below zero but is warmer than the pavement temperature — requiring only that the pavement temperature is below freezing.

As we have already stated, predicting pavement temperature is complicated. Predicting the air temperature for 5:00 pm tomorrow is already a difficult task. If they predict the air temperature incorrectly, it automatically throws off the accuracy of the pavement temperature prediction. In addition, there are a variety of other factors that change quickly and with less notice (air temperature, precipitation, clouds, thickness of the pavement, etc.). That’s why we rely so heavily on site specific RWIS technology for the most accurate prediction of pavement temperature. State DOTs rely heavily on these pavement forecasts to determine when to pretreat roads, when to schedule crews, and how much material will be required throughout the duration of the event in order to ensure your safety.

Despite predictions and precautions, dangerous winter storm conditions are not 100% preventable. Stay safe this winter and listen to winter weather advisories. Even if there is no snow, black ice is a real possibility.
